Kev cob qha Piston Compressor
Nrog dhau 20 xyoo kev paub, HighQ Compressor tshwj xeeb hauv kev tsim thiab ua lag luam piston compressor, uas yog kev ua haujlwm siab tshaj, tsawg zog noj thiab ntev lifespan. Raws li yog ib tus kws tshaj lij thiab cov neeg muag khoom hauv Suav teb, peb zoo siab tos txais koj los yuav cov cuab yeej zoo hauv Tuam Tshoj los ntawm peb lub Hoobkas.
Basic Info
● Qauv NO: V-0.17
● Hom: Piston - Npib Driven
● Kev Ua Tau: Tsawg Qis
● Tsav Tsheb: Fais
● Hwj chim Source: AC fais fab tuag
● Kev Teeb Meem: Nyob ruaj ruaj
● Khoom: Aluminium
● Piston Hom: Kaw
● Lubrication Style: Lubricated
● Mute: Tsis hais lus
● Tsav tus qauv: Siv Driven:
● Hom Tshuaj: OEM Muaj Peev Xwm
● Trademark: HighQ
● Specification: CE TUV
● Keeb Kwm: Tebchaws Suav
● HS Code: 8414809090
Cov Lus Qhia Txog
● Muaj tshaj li ntawm 20 xyoo ntawm kev paub txog kev ua ntej huab cua compressor manufacturing, qhov ntau ntawm cov khoom thiab cov kev pab cuam uas peb muab encompasses innovation tsim nrog zoo ua kev txhawb nqa nrog qib siab ntawm cov khoom pab khoom muag thiab tom qab kev muag khoom.
● Qhov kev mob siab rau qhov zoo tshaj plaws thiab txoj hauv kev tso cai no cia peb xa tus nqi, kev ntseeg, kev yoojyim thiab kev ua tau zoo uas peb txhiab tus neeg thov.
● Nrog kev tiv thaiv thiab muab kev txhim khu kev xyuam xim thiab kev sib haum xeeb rau kev cob qhia thiab cov kev lag luam.
● Peb mas export zoo thiab cua compressors, peb cov compressors nrog kom zoo dua ntawm lub suab nrov, lub zog txuag thiab txhim khu kev qha zoo.
Parameter & Specification (Pump)
Qauv | Lub cev muaj zog zog (kw / hp) | Lub tog raj kheej (inch x Piece) | Pa hauv qhov siab m3 / min | Ua Siab Siab (Mpa) | RPM (r / min) | Dimension (LxWxH cm) | Qhov hnyav (kg) |
HD0208 | 2.2 / 3 | 55 x 2 | 0.25 | 0.7 | 800 | 27x27 x 30 | 20 |
HD2055 | 3/4 | 65 x 2 | 0.36 | 0.7 | 820 | 29x30 x 39 | 15 |
Z-0.036 / 7 | 0.55 / 0.75 | 51 x 1 | 0.005 | 0.7 | 800 | 23x15x27 | 8 |
V-0.08 / 7 | 0.75 / 1 | 51 x 2 | 0.08 | 0.7 | 800 | 95 x 25 x 31 | 18 |
Z-0.10 / 7 | 1.5 / 2 | 55 x 1 | 0.1 | 0.7 | 800 | 27x23x34 | 20 |
V-0.12 / 7 | 1.1 / 1.5 | 51 x 2 | 0.12 | 0.7 | 800 | 35x74x29.5 | 18 |
V-0.17 / 7 | 1.5 / 2 | 51 x 2 | 0.17 | 0.7 | 950 | 36 x 25 x 33 | 20 |
V-0.25 / 7 | 2.2 / 3 | 55 x 2 | 0.25 | 0.7 | 820 | 41x27x36 | 22 |
W-0.36 / 7 | 3/4 | 65 x 3 | 0.36 | 0.7 | 800 | 46.5x27x37 | 28 |
V-0.48 / 7 | 4 / 5.5 | 90 x 2 | 0.48 | 0.7 | 820 | 53 x 30 x 40 | 54 |
W-0.67 / 7 | 5.5 / 7.5 | 80 x 3 | 0.57 | 0.7 | 800 | 52x43x52.5 | 68 |
W-0.9 / 7 | 7.5 / 10 | 90 x 3 | 0.9 | 0.7 | 800 | 93.5x43x52.5 | 73 |
W-1.4 / 7 | 11/15 | 100 x 3 | 1.4 | 0.7 | 780 | 70x62 x 55 | 180 |
W-1.8 / 7 | 15/20 | 120 x 3 | 1.8 | 1.25 | 780 | 93 x 55 x 10 | 210 |
V-0.15 / 12.5 | 1.5 / 2 | 65 x 1/51 x 1 | 0.15 | 1.25 | 950 | 96x25 x 32 | 20 |
V - 0.20 / 12.5 | 2.2 / 3 | 65 x 1/51 x 1 | 0.2 | 1.25 | 820 | 41x27x36 | 22 |
W-0.30 / 12.5 | 3/4 | 65 x 2/51 x 1 | 0.3 | 1.25 | 800 | 46.8 x 20 x 38 | 28 |
W-0.53 / 12.5 | 5.5 / 7.5 | 60x2 / 65 x 1 | 0.53 | 1.25 | 860 | 62x42x52.5 | 68 |
W-0.71 / 12.5 | 7.5 / 10 | 50 x 2/90 x 1 | 0.71 | 1.25 | 800 | 62x43x52.8 | 73 |
W-1.05 / 12.5 | 11/15 | 100 x 2/90 x 1 | 1.05 | 1.25 | 780 | 76x62x88 | 130 |
W-1.50 / 12.5 | 16/20 | 120x2 / 100x1 | 1.5 | 1.25 | 780 | 93x56x90 | 210 |
Nrog dhau 20 xyoo kev paub, HighQ Compressor tshwj xeeb hauv kev tsim thiab kev lag luam ncaj qha tsav piston 0.55kw rau 2.2kw, uas yog kev ua haujlwm siab, tsis muaj zog noj thiab ntev lifespan. Raws li yog ib tus kws tshaj lij thiab cov neeg muag khoom hauv Suav teb, peb zoo siab tos txais koj los yuav cov cuab yeej zoo hauv Tuam Tshoj los ntawm peb lub Hoobkas.
Peb Qhov Kev Pab Cuam
Kev Muag Khoom Tom Qab
1.Cov lus nug lossis thov ua ntej, thaum lossis tom qab kev muag khoom, peb xav pab koj txhua lub sijhawm thiab yuav nrhiav tau koj qhov kev daws teebmeem tshaj 24 teev.
2. Kev tiv thaiv: Ob xyoos rau saum cua tshuab thiab Ib Xyoos rau tag nrho cov tshuab, qhov chaw seem yuav muab nrog tus nqi zoo tshaj.
Kev Pabcuam Tshwj Xeeb Tshwj Xeeb
1) Tas nrho cov OEM
Tus Nqi: 1 pawg no xam tau
Hauv txoj kev npaj no, peb yuav ua txhua yam kev hloov (xim, lub npe phaj thiab lub logo) raws li koj xav tau, thiab yuav tsis kom them tus nqi ntxiv.
FAQ
Q1: Puas yog koj lub Hoobkas lossis Lub Lag Luam?
A1: Peb yog Hoobkas.
Q2: Cov lus cog tseg ntawm koj lub tshuab?
A2: Ob xyoos rau saum huab cua-xaus thiab Ib Xyoos warranty rau lub tshuab tiav thiab kev txhawb nqa raws li qhov koj xav tau.
Q3: Koj puas kam muab qee qhov chaw seem ntawm cov tshuab?
A3: Yog lawm, tau kawg.
Q4: Ua li cas rau cov khoom muag pob?
A4: Peb ntim peb cov khoom nruj me ntsis nrog rooj plaub seaworthy.
Q5: Ua li cas rau qhov khoom hluav taws xob ntawm cov khoom? Lawv puas tuaj yeem ua haujlwm?
A5: Yog lawm, tau kawg. Tus voltage tau customized raws li koj qhov kev sib npaug.
Q6: Lub sijhawm twg them koj txais tau?
A6: 30% T / T down payment thiab 70% T / T tshuav nyiaj.
Q7: Koj yuav siv sij hawm ntev npaum li cas?
A7: 380V 50HZ peb tuaj yeem xa cov khoom nyob rau hauv 7-15 hnub. Lwm cov hluav taws xob yuav yog 30-45 hnub.
Q8: Koj puas txais tau OEM txiav txim?
A8: Yog, nrog rau kev tsim pab pawg, OEM xaj yog txais tos heev.
Q9: Cov nqe lus twg txhais tau?
A9: Muaj cov nqe lus lag luam: FOB, CIF, CFR, thiab lwm yam.
